Mathematik-Online-Test:

MINT HM 1 Online Übungen, Test 8


Dieser Test enthält Aufgaben (A) mit Varianten (V).

Angezeigt:  A1 V28
Variantenauswahl:

Test mit ausgewählten Varianten .


Aufgabe 1:
Gegeben ist der Vektorraum $ \mathbb{R}^4$ über $ \mathbb{R}$ mit dem Standardkoordinatensystem $ \mathbb{E}:=(\vec{0};\mathrm{e}_1,\mathrm{e}_2,\mathrm{e}_3,\mathrm{e}_4)$ und den affinen Koordinatensystemen

$\displaystyle \mathbb{F}:=\left( \begin{pmatrix}0\\ 0\\ 1\\ 0 \end{pmatrix}; \b...
...0\\ 1\\ 0\\ 0 \end{pmatrix}, \begin{pmatrix}1\\ 0\\ 0\\ 0 \end{pmatrix} \right)$   und$\displaystyle \quad \mathbb{G}:=\left( \begin{pmatrix}-1\\ -3\\ -1\\ 0 \end{pma...
... 1\\ 0\\ 0 \end{pmatrix}, \begin{pmatrix}0\\ -1\\ 0\\ -1 \end{pmatrix} \right).$

(a)
Bestimmen Sie die Koordinatentransformation $ {{\strut}_{\mathbb{F}}^{}\kappa{\strut}_{\mathbb{E}}^{}}\colon\mathbb{R}^4\to\mathbb{R}^4,\,{{\strut}_{\mathbb{E}}^{}{v}}\mapsto{{\strut}_{\mathbb{F}}^{}{v}}$.

Antwort:

$ {{\strut}_{\mathbb{F}}^{}\kappa{\strut}_{\mathbb{E}}^{}} \left({{\strut}_{\mathbb{E}}^{}{v}}\right) = \left(\rule{0pt}{10ex}\right.$
0 $ 1$
0 $ 1$
$ 1$ 0
$ 1$ 0
$ \left.\rule{0pt}{10ex}\right){{\strut}_{\mathbb{E}}^{}{v}}$ $ +$ $ \left(\rule{0pt}{10ex}\right.$
$ \left.\rule{0pt}{10ex}\right).$

(b)
Bestimmen Sie die Koordinatentransformation $ {{\strut}_{\mathbb{G}}^{}\kappa{\strut}_{\mathbb{E}}^{}} \colon \mathbb{R}^4 \...
...thbb{R}^4,\,{{\strut}_{\mathbb{E}}^{}{v}} \mapsto {{\strut}_{\mathbb{G}}^{}{v}}$.

Antwort:

$ {{\strut}_{\mathbb{G}}^{}\kappa{\strut}_{\mathbb{E}}^{}} \left({{\strut}_{\mathbb{E}}^{}{v}}\right) = \left(\rule{0pt}{10ex}\right.$
0 0
$ 1$ $ -2$
0 0
$ 3$ $ -4$
$ \left.\rule{0pt}{10ex}\right){{\strut}_{\mathbb{E}}^{}{v}}$ $ +$ $ \left(\rule{0pt}{10ex}\right.$
$ \left.\rule{0pt}{10ex}\right)$.

(c)
Sei die affine Abbildung $ \alpha$ bezüglich des Standardkoordinatensystems $ \mathbb{E}$ gegeben durch

$\displaystyle \alpha\colon\mathbb{R}^4\to\mathbb{R}^4,\,v\mapsto \begin{pmatrix...
...0&-3&-3\\ 0&3&0&0 \end{pmatrix} v + \begin{pmatrix}3\\ 2\\ 2\\ -3\end{pmatrix}.$

Bestimmen Sie $ {{\strut}_{\mathbb{F}}^{}\alpha{\strut}_{\mathbb{G}}^{}}$, das heißt eine Matrix $ A\in\mathbb{R}^{4\times 4}$ und einen Vektor $ t\in\mathbb{R}^4$ so, dass gilt $ {{\strut}_{\mathbb{F}}^{}{\left(\alpha\left({{\strut}_{\mathbb{G}}^{}{v}}\right)\right)}} = A {{\strut}_{\mathbb{G}}^{}{v}} + t$.

Antwort:

$ {{\strut}_{\mathbb{F}}^{}\alpha{\strut}_{\mathbb{G}}^{}} \left({{\strut}_{\mathbb{G}}^{}{v}}\right) = \left(\rule{0pt}{10ex}\right.$
$ 6$ $ -3$
$ 9$ $ -2$
$ -6$ $ 2$
$ -6$ 0
$ \left.\rule{0pt}{10ex}\right){{\strut}_{\mathbb{G}}^{}{v}}$ $ +$ $ \left(\rule{0pt}{10ex}\right.$
$ \left.\rule{0pt}{10ex}\right).$
